IMAGEN DE REFERENCIA

PEN-M5A Fotocelda Retro- reflectiva 0.1-5m de 24-240vca-vcd

0 Reseñas(s)
PEN-M5A

PENM5A Fotocelda Retro- reflectiva 0.1-5m de 24-240vca-vcd

FICHA TECNICA

Envio

¿Necesitas certificado de calibración?, ¡pregunta a tu vendedor favorito vía WhatsApp!

HANYOUNG NUX
Cotizar

PENM5A Fotocelda Retro- reflectiva 0.1-5m de 24-240vca-vcd

 Appearance
Model PEN-T10A PEN-R700A PEN-M5A
Type Through beam Diffuse reflection Retro reflection
Sensing distance 10 m 700 mm 0.1 ~ 5 m
Sensing object Ø 20 mm
(opaque body)		 200 x 200 ㎜
(White non- glossy paper)		 Ø 60 mm
(opaque body)
Power Supply voltage 24 - 240 V 50 Hz / 60 Hz AC ± 10 %
Power consumption Emitter:max 1W
Receiver:max 2W		 max 2 W
Operation mode Light ON / Dark ON ※ selectable by mod V/R
Sensitiviry ad - Built-in the sensitivity
control V/R
Control output
Relay output (Contact composition 1a,1b)capacity : 30 V DC 5 A / 250 V AC 5 A
Resistance load life expectancy - min 100 thousand time
Response time max 20 ms
Response range - within 15% of
detect range		 -
Light source infrared rays LED(alteration)
Material Case : Heat resistance ABX, Lens : P.C
Connection method Cable extended type (Number of wire : 5P, Diameter : Ø 6 ㎜, Length : 2 ㎜) ※ Emitter 2P
Ambient light sun light : 11000 Lux below, Incandescent lamp : 3000 Lux below
Ambient temperature -20 ~ 65 °C (surrounding storge temperature : -25 ~ 70 °C)
Ambient humidity 35 ~ 85 % RH (with no condensation)
Dielectric Strenght AC 1000 V 1 minute
Insulation resistance 20MΩ Min. (At 500V DC between code and case, adjusting switch and case)
