6580 4-VNR VALVULA ANTIRRETORNO (CHECK) 4mm

Referencia 6580 4-VNR

VALVULA ANTIRRETORNO (CHECK) 4mm

6580 4-VNR
Series VNR unidirectional valves

¿Necesitas certificado de calibración?, ¡pregunta a tu vendedor favorito vía WhatsApp!

Series general data

Valve group	automatic valves
Construction	poppet-type
Materials	brass body stainless steel spring NBR/FKM seals (for version 6580)
Mounting	in any position
Ports	M5, G1/8, G1/4, G3/8, G1/2, G3/4, G1
Operating temperature	0°C ÷ 80°C; NBR (with dry air -20 / +80°C ) FKM (with dry air - 20 / +200 °C)
Medium	filtered air without lubrication. If lubricated air is used, it is recommended to use ISO VG32 oil. Once applied the lubrication should never be interrupted.
Tube dimensions	Ø4; Ø6 and Ø8
