IMAGEN DE REFERENCIA

  • Sobre pedido

MX3-1-R402 REGULADOR 1PUL, 0-4 BARS

0 Reseñas(s)
MX3-1-R402

REGULADOR 1", 0-4 BARS

MX3-1-R402
Pressure regulators Series MX - dimensions

Envio

¿Necesitas certificado de calibración?, ¡pregunta a tu vendedor favorito vía WhatsApp!

CAMOZZI
Cotizar
Code properties

Mod. A B (bar) C D E F G H I M N P Q R S T U Weight (Kg)
MX3-1-R004 G1 0 ÷ 12 89,5 54 Ø 4 M57x1,5 75 81 76 45 206 104 5 102 57,5 44,5 0 ÷ 20 1
Series general data

Construction modular, compact, diaphragm type
Materials see TABLE OF MATERIALS on the following page
Ports MX2: G3/8 - G1/2 - G3/4 - MX3: G3/4 - G1 Manifold regulator: G1/2 (MX2 only)
Mounting vertical in-line, wall-mounting (by means of clamps), panel mounting
Operating temperature -5°C ÷ 50°C up to 16 bar (with the dew point of the fluid lower than 2°C at the min. working temperature) -5°C ÷ 60°C up to 10 bar (with the dew point of the fluid lower than 2°C at the min. working temperature)
Inlet pressure 0 ÷ 16 bar
Outlet pressure 0.5 ÷ 10 bar (standard) 0 ÷ 4 bar 0.5 ÷ 7 bar (MX2 only)
Overpressure exhaust with relieving (standard) or without relieving
Nominal flow see FLOW DIAGRAMS on the following pages
Fluid compressed air
Pressure gauge built-in pressure gauge (standard) with G1/4 port (MX3 only) or G1/8 port (MX2 only)
