Product Specifications

Dimensions (in.)

3 7/32 in. high x 2 7/32 in. wide x 3 1/16 in. deep

Dimensions (mm)

81.8 mm high x 56.4 mm wide x 77.8 mm deep

Temperature Range (F)

-20 F to +105 F

Temperature Range (C)

-29 C to +41 C

Item Type

Product

Mounting

Foot-mounted

Electrical Ratings

Primary voltage--120 Vac; Secondary voltage--26.5 V.O.C.

Frequency

50 Hz; 60 Hz

Approvals, Underwriters Laboratories Inc.

UL Component Recognized.

Approvals, Canadian Standards Association

Certified

NEMA Rating

NEMA type D

Approvals, N.E.C.

NEC Approved.

Electrical Connections (Primary)(in.)

1/2 in. male conduit spud with 9 in. leadwires

Electrical Connections (Primary)(mm)

13 mm male conduit spud with 9 in. leadwires

Electrical Connections (Secondary)(in.)

(2) screw terminals

Electrical Connections (Secondary)(mm)

(2) screw terminals

Electrical Ratings, Output

24 Vac at 40 VA
