Actuator Operating Voltages:
220Vac±10%, 110Vac±10% 24Vac±10% 50/60Hz

Control mode:
Spring Return, Port “A” -

Open Working temperature: 0~50°C

Working relative humidity: 10%~90%RH, non-condensating

Power consumption: ≤7VA

Nominal Timing:

Open: ≤20s

Shut: ≤15s

Protection rating: IP20

Valve Applicable medium: cold or hot water or 50% glycol solution

Fluid temperature: 0~94°C

Operating temperature: 0~50°C

Operating relative humidity: 10%~90%RH, non condensating

Nominal pressure: PN20

Leakage rate: 0.05%kvs

Materials:

Valve body: HPb59-2

Valve rod: HPb59-2

Valve flap: EPDM
