Features:

• Designed with MICRO SWITCH™ BZ, BM, or DT basic switches to deliver precise switching of electrical and mechanical operating characteristics
• MICRO SWITCH™ E6 Side Mount and V6 Flange Mount with Features and Options
• High capacity (22 A) available with BME6 Series switch
• Small footprint with easy access to wiring terminals
• Available in a configuration suited to the application with variety of actuators, circuitries, connectivity, and mounting options
• Standard temperature range is -32 C to 71 C [-25 F to 160 F] with an optional -40 C [-40 F] low temperature
• UL, CSA, and CE certified for most SPDT catalog listings
• DPDT catalog listings are UL and CSA certified
• E6 NEMA 1
• V6 NEMA 1, 3
• Epoxy filled NEMA 1, 3, 4, 12, 13
• Preleaded or connector termination options

  Applications:
• Packaging equipment (balers, door interlocks)
• Air curtains (control of air movement)
• Conveyors (diverters, gates)
• Construction machinery and equipment (door and panel interlocks)
• Rail maintenance equipment (door and panel interlocks, position sensing)
• Agricultural equipment (grain handling)
