Power supply 24 V DC +/- 10%, max absorption 1.5 A

Command signal +/- 10 V 0-10 V 4-20 mA

Hysteresis 1% FS LRWD2 - 0,2% FS LRPD2 Linearity 1% FS LRWD2 - 0.3% FS LRPD2

Switching time see the following pages Working temperature from 0 to 50° C

Relative humidity of air max. 90%

Direction of assembly any Maximum flow see the diagrams on the following pages

Medium filtered compressed air, unlubricated, according to ISO 8573-1 class 3.4.3, inert gas

Supply pressure -0.9 to 10 bar Leakage < 1% of maximum flow rate

Electrical connection male connector M12 8 poles Hardware configuration port micro USB
