E SERIES

5 FUNCTION:
2 = 5/2 (5 ports/2 positions) supply from the exhausts
5 = 5/2 (5 ports/2 positions)
6 = 5/3 centre closed
7 = 5/3 centre open
8 = 5/3 pressure centre

3 SIZE:
2 = size 10,5
3 = size 16
5 = size 19

1 BODY TYPE: 1 = body with threaded plate

11 ACTUATION:
11 = electro-pneumatic, bistable
16 = electro-pneumatic, monostable
33 = pneumatic bistable - tube 3
36 = pneumatic monostable - tube 4
C33 = pneumatic bistable - tube 4
C36 = pneumatic monostable - tube 4

15 INTERFACE:
10
15

P TYPE OF SOLENOID:
K
P
W

5 SOLENOID DIMENSION:
1 = 10x10
5 = 15x15

3 SOLENOID VOLTAGE:
1 = 6V DC (size 10,5)
2 = 12V DC (size 10,5)
3 = 24V DC (size 10,5 - 16 - 19)
4 = 48V DC (size 16 - 19)
6 = 110V DC (size 16 - 19)
L = 12V 50/60 Hz (size 16 - 19)
B = 24V 50/60 Hz ( size 16 - 19)
C = 48V 50/60 Hz (size 16 - 19)
D = 110V 50/60 Hz (size 16 - 19)
