Analog: 0-100mV, 0-5V, 1-5V, 0-10V
0-20mA, 4-20mA Sampling cycle 50ms Control output 1 Current(DC0/4-20mA) or SSR drive(11VDC ⎓) [ON/OFF] Option input CT, Digital(DI-1) Option output Alarm 1/2 Power supply 24VAC~ 50/60Hz, 24-48VDC @(=) Protection structure IP65(front panel) Approval  Display accuracy_RTD •At room temperature(23?±5?):(PV ±0.3% or ±1?, select the higher one) ±1-digit
•Out of room temperature:(PV ±0.5% or ±2?, select the higher one) ±1-digit Display accuracy_Thermocouple •At room temperature(23?±5?):(PV ±0.3% or ±1?, select the higher one) ±1-digit
•Out of room temperature:(PV ±0.5% or ±2?, select the higher one) ±1-digit Display accuracy_Analog •At room temperature(23?±5?): ±0.3% F.S. ±1-digit
•Out of range of room temperature: ±0.5?% F.S. ±1-digit Display accuracy_CT input ±5% F.S. ±1-digit Hysteresis(adjustable sensitivity) RTD/Thermocouples: 1 to 100℃/℉(0.1 to 100.0℃/℉) variable Analog: 1 to 100-digit Proportional band 0.1 to 999.9?/?(0.1 to 999.9%) Integral time 0 to 9999 sec Derivative time 0 to 9999 sec Control period Relay output, SSR drive output: 0.1 to 120.0 sec Current output or SSR drive output selectable: 1.0 to 120.0 sec Manual reset 0.0 to 100.0% Environment_Ambient temperature -10 to 50?, storage: -20 to 60℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Insulation type Double insulation or reinforced insulation(mark: @(INS), dielectric strength between the measuring input part and the power part: 2kV) Weight Approx. 150g(approx. 105g)
