MRX-RM1A0R PUSH BOTON ILUMINADO ROJO GUARDA ALUMINO EXTENDIDA 100-240VAC 22MM MOMENTARI

Referencia MRX-RM1A0R

¿Necesitas certificado de calibración?, ¡pregunta a tu vendedor favorito vía WhatsApp!

Specification

Contact composition		1a1b
Contact action		Snap-action
Installing panel thickness		7.0 ㎜ (when excluded the additional accessories)
Material	Contact material	AgSnO₂
Material	Contact body material	Polycarbonate(P.C)
Mechanical characteristic	Fixed torque	Installing nut : 1.96 N•m max, Installing nut : 0.78 N•m max
	Operating power	6.47 N (operation part + 1a1b contact)
	Operating distance	5 ㎜ ±0.2
	Reflection time	max 3 ㎳
	Durability of actuator	Button: min 500 thousand times, Selector switch: min 200 thousand times
Electrical characteristic	Dielectric strength	2,000 V a.c. 1 min
	Contact resistance	max 50 ㏁ (Initial setting)
	Insulation resistance	min 100 ㏁ 500 V d.c.
	Rated current	6 A 250 V a.c.
	Min load current	5 ㎃ 24 V d.c., 10 ㎃ 110 V d.c.
	Min load current	200 thousand times
Power supply voltage	Power supply voltage	100 - 240 V a.c. (ED condenser voltage dropping type)
		380 V a.c. (LED condenser voltage dropping type)
		12 - 24 V d.c./a.c. (LED resistance voltage dropping type)
Buzzer volume		Approx. 90 dB
Environment condition	Ambient temperature	-20 ~ 55 ℃
	Ambient temperature	35 ~ 85 % RH
	Storage temperature	-40 ~ 85 ℃
	Shock resistance	300 ㎨ pulse cycle 11 ㎳
	Vibration resistance	100 ㎨ 10 - 55 ㎐, amplitude 0.75 ㎜ (within 1 ㎳ )
