MA4NA Timer 48x48mm 11 pin con dial multirango, multifunción y multivoltaje 24-240vca - 6-240vcd 2 contactos de retardo

MA4NA

MA4NA Timer 48x48mm 11 pin con dial multirango, multifunción y multivoltaje 24-240vca -  6-240vcd 2 contactos de retardo

FICHA TECNICA

Envio

¿Necesitas certificado de calibración?, ¡pregunta a tu vendedor favorito vía WhatsApp!

MA4NA Timer 48x48mm 11 pin con dial multirango, multifunción y multivoltaje 24-240vca -  6-240vcd 2 contactos de retardo.

- Unidad de tiempo 4 tipos - Multi gama 4 clases - Reset, inicio, entrada prohibida - Modo de funcionamiento de salida 6 tipos.

Model MA4N-A MA4N-B MA4N-C
Power Supply voltage 24 - 240 V a.c / d.c 50 - 60 Hz
Voltage regulation ±10 % from supply voltage
Power consumption 5.3 VA (240 V a.c), 2.5 W (240 V d.c)
Resetting time Max. 0.1 sec
Min Signal
length
START Input Min. 20 ms -
INHIBIT Input
RESET Input
Input
condition
START Input Non voltage Input
Impedance in a short circuit : Max. 2 kΩ
Residual voltage in a short circuit : Max. 0.7 V d.c
Impedance in open : Min. 100 kΩ
-
INHIBIT Input
RESET Input
Output Time Limit 2c Time Limit 1c
Instautaneous 1c
Time Limit 2c
Time Limit 1c
Instautaneous 1c
N.O : 10 A 125 V a.c, 5 A 250 V a.c, 5 A 30 V d.c
N.C : 3 A 125 V a.c, 2 A 250 V a.c, 1 A 30 V d.c
Setting error Max. ± 5 % ± 0.05 sec -
Repeat error Max. ± 0.3 %
Temperature error Max. ± 2 %
Insulation resistance Min. 100 MΩ (Base on 500 V d.c)
Dielectric strength 2000 V a.c 50 / 60 Hz for 1 min.
Impulse voltage ± 2000 V Max.
Vibration Mechanical
Resistance
10 - 55 Hz double amplitude 0.75 mm
Malfunction
durability
10 - 55 Hz double amplitude 0.5 mm
Shock Mechanical
Resistance
300 m/s² (Approx. 30 G)
Malfunction
durability
100 m/s² (Approx. 10 G)
Life Mechanical Over 10 million operations (Open & Short frequency : 180 / min)
Electrical Over 100,000 (250 V a.c 3 A load resistance)
Terminal type Socket type 11 pin Socket type 8 pin
Ambient temperature -10 ~ 55 ℃ (With no condensation)
Conservation temperature -20 ~ 65 ℃ (With no condensation)
Ambient humidity 35 ~ 85 %R.H.
Weight About 100g (Including fixing bracket)
